3L.P.GAS "LEVEL
CONTROL" L.P.G. vaporizer represent a step ahead in the manufacturing of L.P.G.
vaporization systems; the only system of its kind, it allows electronic and internal
liquid-phase-level control and output signals management (intrinsic protection method) on
a perneed basis, through its connection to the storage tank's liquid-phase (see operation
diagram).
The above mentioned device (click here to download complete Technical
Specification see detail # 4) provides
moment-by-moment liquid-level depth measurement inside the vaporizer, and sends a real
time valve-shutoff signal to the LPG liquid-phase suction valve (electrical or pneumatic,
see details # 9-10) whenever the system threshold is exceeded.
Visual and/or acoustic prealarm systems are available, as well as a PLC.
All vaporizers are entirely built in accordance with applicable laws and are individually
tested at 27 bars (water and gas pipes); series production (see tables W & E) is
subject to expansion to suit customer demand and meets any type of required capacity.
|
|
|
